TuffStuff - Apollo 7200 2-Station Multi Gym System (AP-7200) - Add-Ons
Base Item
Overview
The Apollo series is your go-to solution for creating a dynamic, high-performance gym space tailored to your needs.
SKU: SKU: KIT1545
Online Availabilty
IN-STORE Availability
Call your Local Treadmill Factory for IN-STORE availability
Overview
The Apollo series is your go-to solution for creating a dynamic, high-performance gym space tailored to your needs.
WEIGHT | 1030 lbs |
DIMENSIONS | 88"L × 82"W × 84"H |
FRAME | Main frame – 2×3” 11-gauge oval tubular steel with a combination of 2×2” round tubing. All welded construction by inert-gas MIG welding conforming with all Structural Welding Code-Steel Standards and Specifications. |
FINISH | Eight-step electrostatically applied powder coat finish. Main frame: Platinum Sparkle Accent: Cathedral Gray. |
UPHOLSTERY | Premium grade naugahyde formulated to resist bacteria, stains, mildew and oil. Meets most flammability test requirements. Standard two-tone (Black/Cadet) and double-stitched with “hidden” borders. Custom colors (one-tone) are available – inquire with your sales representative. |
PADDING | High density 2” thick rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit. |
CABLES | 2,200 lbs. test 3/16” military-spec nylon coated cable. |
WEIGHT STACK | 2 Weight Stacks: black painted solid steel weight plates (200 lbs.) with self aligning low friction sleeves. |
ADJUSTMENT PINS | 1/2” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength. |
BEARINGS | 1” solid steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots. |
GUIDE RODS | 3/4” solid steel 1045 (tgp) highly polished chrome-plated finish. |
PULLEYS | 4-1/2” and 3-1/2” fiberglass-impregnated nylon pulleys with double sealed roller bearings. |
SELECTOR WEIGHT PINS | Solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss. |
FASTENERS | All frame bolts and nuts are 3/8” and 1/2” zinc plated. Meets ANSI specifications. |
HOME WARRANTY | Lifetime on everything to the original purchaser when used only in a HOME environment, applies to defects from manufacturer only |
LIGHT COMMERCIAL WARRANTY | 10 YEARS: Structural main frames, welds, cams and weight plates.
5 YEARS: Pivot bearings, pulleys, bushings, guide rods and gas shocks. 1 YEAR: Cables, linear bearings and pull-pin components. 6 MONTHS: Upholstery, finish and rubber grips. ALL OTHER PARTS not mentioned, one year from the date of purchase to the original purchaser. |
Specifications | |
---|---|
Gym Dimensions | 88"L x 82"W x 84"H |
Gym Weight | 1030 lbs |
Model # | 7200 |
